Sensors

ESYLUX - DALI

  Print this Page

    Features

    Simple planning and installation with the confidence of  efficient light control.

    Quality German manufacture

  • ESYLUX Compact MINI Sensors - DALI Control
    Code Description
    LHT0306_Compact_Mini_6m
    EP10427503

    ESYLUX Compact MINI PIR Sensor - PD-C 360i/6 Mini DALI

    360° Downward Presence Detection, 6m Range

    Broadcast DALI for room based control (DALI power supply required - see below)


    Ceiling mount, 20mm dia. cut-out, 1-240 min Delay OFF


    Class III, IP65

    LHT0307_Compact_Mini_8m
    EP10427510

    ESYLUX Compact MINI PIR Sensor - PD-C 360i/8 Mini DALI

    360° Downward Presence Detection, 8m Range

    Broadcast DALI for room based control (DALI power supply required - see below)

    Ceiling mount, 25mm dia. cut-out, 1-240 min Delay OFF


    Class III, IP65

  • LHT0493
    EP10427541

    ESYLUX Flat PIR Sensor - PD-Flat 360/8i Round White DALI

    360° Downward Presence Detection, 8m Range

    Broadcast DALI for room based control (DALI power supply required - see below)

    White round trim, Recess or surface ceiling mount (kits required - see below)

    1-240 min Delay ON (adjustable)

    2300W (Resistive) 600W (LED), Class II, IP20

    EP10427541

    LHT1065
    EP10427916

    ESYLUX Flat PIR Sensor - PD-Flat 360/8i Round Black DALI

    360° Downward Presence Detection, 8m Range

    Broadcast DALI for room based control (DALI power supply required - see below)

    Black round trim, Recess or surface ceiling mount (kits required - see below)

    1-240 min Delay ON (adjustable)

    2300W (Resistive) 600W (LED), Class II, IP20

    LHT0495
    EP10427558

    ESYLUX Flat PIR Sensor - PD-Flat 360/8i Square White DALI

    360° Downward Presence Detection, 8m Range

    Broadcast DALI for room based control (DALI power supply required - see below)

    White square trim, Recess or surface ceiling mount (kits required - see below)

    1-240 min Delay ON (adjustable)

    2300W (Resistive) 600W (LED), Class II, IP20

    LHT1066
    EP10427909

    ESYLUX Flat PIR Sensor - PD-Flat 360/8i Square Black DALI

    360° Downward Presence Detection, 8m Range

    Broadcast DALI for room based control

    Black square trim, Recess or surface ceiling mount (kits required - see below)

    1-240 min Delay ON (adjustable)

    2300W (Resistive) 600W (LED), Class II, IP20

    LHT1038_-_2108_-_Esylux_Flat_PIR_Sensor_Accessory_-_Polished_Glass_Trim_
    EP00007255

    ESYLUX Flat PIR Sensor Accessory

    Polished Glass Trim (cover only) - 94mm Round White

    LHT1037_-_2108_-_Esylux_Flat_PIR_Sensor_Accessory_-_Polished_Glass_Trim_Black_
    EP00007293

    ESYLUX Flat PIR Sensor Accessory

    Polished Glass Trim (cover only) - 94mm Round Black

    LHT1040_-_2108_-_Esylux_Flat_PIR_Sensor_Accessory_-_Polished_Glass_Trim_Square_White_
    EP00007262

    ESYLUX Flat PIR Sensor Accessory

    Polished Glass Trim (cover only) - Square White

    LHT1039_-_2108_-_Esylux_Flat_PIR_Sensor_Accessory_-_Polished_Glass_Trim_Square_black
    EP00007309

    ESYLUX Flat PIR Sensor Accessory

    Polished Glass Trim (cover only) - Square Black

    LHT1045_-_2108_-_Esylux_Flat_PIR_Sensor_Accessory_-_Trim_White
    EP10428579

    ESYLUX Flat PIR Sensor Accessory

    Oversize Trim (cover only) - 104mm Round White

    Required for surface mounted sensors and solution for oversize holes

    LHT1046_-_2108_-_Esylux_Flat_PIR_Sensor_Accessory_-_Trim_Black
    EP10428098

    ESYLUX Flat PIR Sensor Accessory

    Oversize Trim (cover only) - 104mm Round Black

    Required for surface mounted sensors and solution for oversize holes

  • LHT0301_-_Esylux_Compact_PIR_Accessory_-_Basket_Guard_copy
    EM10425608

    ESYLUX PIR Sensor Accessory

    Basket Guard - IK10

    LHT0302_-_2108_-_Esylux_PIR_Sensor_Accessory_-_Recess_Mount_Kit_copy
    EP10426889

    ESYLUX PIR Sensor Accessory

    Recess Mount Kit

    LHT0321_-_2108_-_Esylux_Compact_PIR_Sensor_-_White_Surface_Mount_Kit
    EP10425905

    ESYLUX PIR Sensor Accessory

    White Surface Mount Kit - IP54

    104mm oversize trim also required

    LHT1144_-_2108_-_Esylux_Compact_PIR_Sensor_-_black_Surface_Mount_Kit
    EP10426940

    ESYLUX PIR Sensor Accessory

    Black Surface Mount Kit - IP54

    Requires either an 8m or 24m/32m black trim kit

    LHT0565_-_2107_-_ELC_SmartDriver_Accessories_-_Switch_DALI_Semi-Automatic_
    EC10430008

    ESYLUX PIR Sensor Accessory

    DALI Power Supply - 200mA

    Optional power supply for DALI Bus

    LHT0556_-_2107_-_Alva_Bollards_540mm_Accesssories_-_Remote_Control_
    EP10425899

    ESYLUX PIR Sensor Accessory

    Remote Control Mobil - PDi/DALI

    LHT1053_-_2107_-_ELC_SmartDriver_Accessories_-_EsyPen_
    EP10425356

    ESYLUX PIR Sensor Accessory

    Remote Control Esy-PEN
